2023 BH Engineering ****RETURNING**** (NEW) 20 HP Air Screw Compressor with air dryer and holding tank. #NBM2391
2023 BH Engineering ****RETURNING**** (NEW) 20 HP Air Screw Compressor with air dryer and holding tank. #NBM2391
Canada
Description
2023 BH Engineering (NEW) 20 HP Air Screw Compressor with air dryer and holding tank
- 20 Horse Power
- 600V, 18A
- Quiet and Power Saving
- Output is continuous and uniform
- 10-15 year lifespan
- includes air dryer
- Free Installation
For pricing please click “REQUEST QUOTE” wherever you see it on our Brighton Woodworking Machinery website at www.brightonmachines.com.
Click <LEASE> for leasing information.
Click <SHIP> for shipping information.
* All Descriptions, Specifications and Features are correct to the best of our knowledge. Interested buyers should verify before purchasing.
Specifications
| Manufacturer | BH Engineering |
| Model | ****RETURNING**** (NEW) 20 HP Air Screw Compressor with air dryer and holding tank. |
| Year | 2023 |
| Condition | New |
| Stock Number | NBM2391 |
| Quality | Excellent |
| Electrics | 600V / 3Ph / 60 Hz |
Additional Features
Air-cooled screw machine:
Model: BMVF15
Screw set 5:6 toothed rotor
compression method continuous, Single-stage
Compressed air outlet pressure P2 = 0.65-1.0MPa
cooling method air cooling
Compressed air outlet temperature 10°C-15°C higher than ambient temperature
amount of lubricating oil ~10 liter
Motor speed N = 2936 r/min
rated power 15 KW
Exhaust volume V = 2.05-2.35 m³/min
working weight ~250KG
Air temperature upper limit 45°C
Air temperature lower limit 0°C
Consumption of lubricating oil Exhaust oil content is less than 3PPM
Noise decibel 73dB(A)
Dimensions (mm) 1000×670×1090
Refrigerated Compressed Air Dryer included:
Model AR-30F
Volume of air processing 3.0 Nm³/min
Intake air temperature ≤45°C
The refrigerant R22
working pressure 1.0 Mpa
pressure dew point 2-10°C
Dimensions (mm) 780×460×750
