*SOLD* Router, Manual Pin - SCM R9N
Sold
*SOLD* Router, Manual Pin - SCM R9N
Location:Uxbridge, Canada
Description
Very clean, well maintained used SCM R9-N overhead router. Foot pedal controlled with 2 speeds.
Used SCM R9N Manual Pin Router. REF# 1816BM-C.
Located in Ontario at our Brighton Woodworking Machinery Warehouse in Uxbridge, 20min E of 404 on Davis Drive.
Specifications
| Manufacturer | SCM |
| Model | R9-N |
| Condition | Used |
| Stock Number | 1816BM-C |
| Electrics | 575 V / 3 Ph / 60 Hz |
| Weight | 1430 lbs |
| Shipping dimensions | 4ft x 7ft x 6ft high |
| Condition info | Very Good |
Additional Features
Model R9
Spindle to frame 900mm
Max/min distance from chuck to table 300x20mm
Cutter head travel 100mm
Table size 905x770mm
Table rise and fall movement 200mm
Spindle speeds 10000 & 20000rpm
Feed speeds using 60mm dia rollers 1.2-3.6m/min
6.6 KW main motor, 9 amp
