*SOLD* Overhead Pin Router - SCM R9
Sold
*SOLD* Overhead Pin Router - SCM R9
Location:Uxbridge, Canada
Description
5.5HP Used SCM R9 overhead pin Router. REF# 1870BM.
Located in Ontario at our Brighton Woodworking Machinery Warehouse in Uxbridge, 20min E of 404 on Davis Drive.
Specifications
| Manufacturer | SCM |
| Model | R9 |
| Condition | Used |
| Stock Number | 1870BM |
| Electrics | 575 V / 3 Ph / 60 Hz |
| Weight | 1430 lbs |
| Shipping dimensions | 32" x 72" x 71" high |
| Condition info | Very Good |
Additional Features
Table dinemsions 905mm x 770mm.
Vertical stroke of table: 200mm.
Vertical stroke of chuck: 100mm,
Min. distance between table and chuck: 200mm.
Max. distance between table and chuck: 300mm.
Standard morse taper adapter MK2.
Spindle speed 10,000 and 20,000 rpm.
Main motor 5.5 hp.
Max working height 1400mm.
Standard machine net weight 650kg.
Manuals included.
