2006 *SOLD* Edgebander - SCM Olimpic K208
2006 *SOLD* Edgebander - SCM Olimpic K208
Location:Uxbridge, Canada
Description
Specifications
Manufacturer | SCM |
Model | Olimpic K208 |
Year | 2006 |
Condition | Used |
Stock Number | 1892BM |
Electrics | 380 V / 3 Ph / 60 Hz (includes transformer for 600 volt) |
Weight | 2500 lbs |
Shipping dimensions | 14ft x 4ft x 6ft high. |
Condition info | Very Good |
Additional Features
25 Amps
5/16" (8 mm) Max. edge cap.,
2" max. banding height, 2-3/8" min. panel width and 6-1/4" min. length.
Equipped with:
Automatic strip & coil feed magazine w/Heavy Duty 3 mm PVC cap. guillotine,
Teflon coated glue pot with glue roller application system complete w/automatic recylcling device for unused glue,
Pre-melt glue system,
digital thermostat adjustment for temperature control;
3-roll pressure section w/pneumatic controls for all pressure wheels.
Workstations:
Double motor front & rear end trim (0.4 HP - 12,000 RPM motor ea.),
tilts 0° - 15°,
end trimmers mounted on 45° THK guide;
top & bottom flush trims (0.8 HP - 12,000 RPM motor ea.),
bevels 0ø - 15°; top & bottom fine/radius trimmer w/pneumatic positioning from control panel.
Top & bottom PVC scraper for up to 5 mm radius.
Last Station:
Top & bottom buffing unit (0.33 HP - 2,800 RPM motors).
Single 42 FPM fixed feed speed,
1 HP drive.
