General International 30-100M1 Thickness Planer
Sold
General International 30-100M1 Thickness Planer
Location:Uxbridge, Canada
Description
Used 13" General International Model 30-100M1 Thickness Planer. REF# 1947BM-C.
Note: Mfg year is not available
Specifications
Manufacturer | General International |
Model | 30-100M1 |
Year | 1901 |
Condition | Used |
Stock Number | 1947BM-C |
Electrics | 220 V / 1 Ph / 60 Hz |
Weight | 275 lbs |
Shipping dimensions | 24" x 20" x 45" high |
Condition info | Very Good |
Additional Features
Fully enclosed stand protects motor from dust and provides a stable work station.
Cast-iron table, base and head reduce vibration.
Four-post design provides added stability to keep the table aligned with the cutter head.
Totally enclosed fan cooled (T.E.F.C) heavy-duty industrial motor.
Planing knives do not need to be removed when switching to molding, making set-up simple.
Two (2) rubber drive rollers prevent damage to the work piece.
Cutting width: 13"
Max thickness: 6 3/4"
Max depth of cut: 1/8"
Spiral cutterhead: no
Knives: 3
Cutterhead diameter Max speed: 4,500 rpm
Cabinet Table depth: 17 3/4", width: 14 1/8"
Table type: Cast Iron
Power: 1- 1/2 HP
Voltage: 220V
single-phase
275 lbs
